1700MM Stainless Steel Industrial Double Bowl Sink With Mild Steel Legs

Description

Overall Dimensions

• Length: 1700 mm
• Depth (front–back): 600–700 mm (700 mm is common)
• Height: 850–900 mm (floor to top edge)

Example: 1700 × 700 × 850 mm

Bowls (2 × Sink Bowls)

• Number of bowls: 2
• Typical internal size (each):
  • Length: 400–500 mm
  • Width (front–back): 400–500 mm
  • Depth: 250–350 mm

Example: 450 × 450 × 300 mm (L × W × D, internal each bowl)

• Corners: Rounded internal corners (easy cleaning)
• Layout: Two bowls side‑by‑side, with small work/drain area at one end or between bowls (depending on design)

Material & Construction

• Stainless grade (recommended):
  • AISI 304 (food grade)
  • Budget: AISI 201 or 430
• Top & bowl thickness: 1.0–1.2 mm stainless sheet
• Finish: Brushed/satin finish on visible surfaces
• Edges:
  • Front & sides: safety folded (double fold)
• Backsplash:
  • 50–100 mm high upstand along rear (typical on commercial sinks)

Frame, Legs & Shelf

• Frame/legs: Stainless steel square tube
  • Typically 38 × 38 mm or 40 × 40 mm, 1.0–1.2 mm thick
• Legs: Normally 4 legs (some designs use 6)
• Feet: Adjustable bullet feet (plastic or stainless) for leveling
• Undershelf (optional):
  • Stainless sheet 0.8–1.0 mm, fixed between legs for storage

Plumbing

• Waste outlets:
  • 1 outlet per bowl (e.g. 1½” or 2″ BSP)
  • With basket strainers and plugs
• Overflow: Optional, depending on design
• Tap/faucet holes:
  • 1–2 holes on backsplash for mixer tap (or left blank as requested)

Example ready‑to‑order spec line

1700 × 700 × 850 mm double‑bowl stainless steel sink, 2 bowls each approx. 450 × 450 × 300 mm deep, top & bowls in 1.2 mm AISI 304 with 100 mm rear backsplash, 40 × 40 × 1.2 mm SS tube frame with 4 legs and stainless undershelf, adjustable bullet feet, 2 × 1½” waste outlets with basket strainers, tap holes in backsplash as required.
