Depth (front–back): 700 mm (common for pot sinks; 600 mm if space is tight)
Working height: 850–900 mm (floor to top edge)
Example overall size: 1700 × 700 × 850 mm
2. Sink Bowls (Double Pot)
Number of bowls: 2
Type: Deep “pot sink” bowls for large pots and pans
Typical internal bowl size (each):
Width (left–right): 500–600 mm
Front–back: 500–600 mm
Depth: 350–450 mm
Example: 550 × 550 × 400 mm deep (L × W × H, internal each bowl)
Corner radius: Rounded internal corners for easy cleaning
Position:
Usually two bowls side‑by‑side, with a small work/drain area at one end or between bowls (depending on design)
3. Material & Construction
Stainless grade (recommended):
AISI 304 (food‑grade, corrosion‑resistant)
Budget alternative: AISI 201 or 430 (less corrosion resistant)
Top & bowls thickness:
1.0–1.2 mm stainless sheet (heavier is better for pot sinks)
Finish:
Brushed / satin finish on exposed surfaces
Edges:
Front & sides: safety folded (double fold) to remove sharp edge
Backsplash / upstand:
50–100 mm high along the back with turned edge
4. Frame, Legs & Shelf
Frame & legs: Stainless steel tube
Typically 40 × 40 mm square tube, 1.0–1.2 mm wall thickness
Number of legs: Usually 4 legs; some heavy‑duty designs use 6 legs
Feet: Adjustable bullet feet (plastic or stainless) for leveling
Undershelf (optional but common):
Stainless steel sheet 0.8–1.0 mm
Fixed between legs for pot/tray storage
5. Plumbing Details
Waste outlets (per bowl):
1 × waste outlet each (e.g., 1½” or 2″ BSP)
Basket strainer and plug (stainless or heavy‑duty plastic)
Overflow: Optional (often omitted on deep pot sinks)
Tap / faucet holes:
1–2 pre‑punched holes on backsplash for wall or deck‑mounted mixer,
or left blank on request
6. Load & Use
Designed for heavy items (pots, trays, containers):
Typical load capacity: 200–350 kg evenly distributed (with proper bracing)
7. Example ready‑to‑order spec line
1700 × 700 × 850 mm double‑pot stainless steel sink, 2 bowls each approx. 550 × 550 × 400 mm deep, top and bowls in 1.2 mm AISI 304 with 100 mm rear backsplash, 40 × 40 × 1.2 mm SS tube frame with 4 legs and stainless undershelf, adjustable bullet feet, 2 × 1½” waste outlets with basket strainers, tap holes in backsplash as required.
