1700MM Splash Back Stainless-Steel Table 0.7 Thick With Mild Steel Legs

Description

1. Dimensions

• Length: 1700 mm
• Depth (front–back): typically 600 mm or 700 mm
• Working height: 850–900 mm from floor to top surface

(Example standard size: 1700 × 700 × 850 mm)

2. Table Top

• Material: Stainless steel, preferably AISI 304 (food grade)
  • Budget option: AISI 201 or 430
• Thickness (top sheet): 1.2–1.5 mm (18–16 gauge)
• Finish: Brushed / satin finish
• Edges:
  • Front & sides: safety folded (double fold) to remove sharp edge
  • Back:
    • Flat, or
    • With upstand/back splash 50–100 mm high (optional)

3. Frame & Legs

• Material: Stainless steel tube
• Legs: 4 legs, typically:
  • 38 × 38 mm or 40 × 40 mm square tube
  • Wall thickness: 1.0–1.2 mm
• Bracing:
  • Side & rear bracing rails or full undershelf (see below)
• Feet:
  • Adjustable bullet feet (plastic or stainless) for leveling on uneven floors

4. Undershelf (Optional but common)

• Material: Stainless steel sheet
• Thickness: 0.8–1.0 mm
• Mounting: Fixed between legs, sometimes height‑adjustable
• Use: storage for trays, pans, small equipment

5. Load & Use

• Typical load capacity: 150–300 kg evenly distributed (varies with tube size/bracing)
• Usage:
  • Dough prep, packing, general food prep
  • As a stand for smaller machines (scales, small mixers, sealers, etc.)

6. Example Spec Line (for ordering)

1700 × 700 × 850 mm stainless steel work table, top in 1.2 mm AISI 304 with front & side safety folds, 50 mm rear backsplash, 40 × 40 × 1.2 mm SS tube frame and legs, single stainless undershelf, adjustable bullet feet.
